| Feature | Unit | Value |
|---|---|---|
| Communication | USB-UART Bridge | |
| Data rate | kBaud | Max. 115 |
| Current load | UFO compact channel strips | |
| 5 V leads | A | 3 |
| 12 V leads | A | 2 |
| 31 V leads | mA | Typ. 11 |
| Interfaces | ||
| Backplane | Connector (f), 40-pin | |
| Voltage supply | 8-core cable and plug | |
| Communication | 6-pin mini-DIN connector | |
| System data | ||
| Power consumption | W | < 1 |
| EMC | dBpW | Max. 20 (EN 50083-2, A1) |
| Temperature range | °C | -20 ... +50 |
| Dimensions (H x W x D, without cable) | mm | 114 x 42 x 23.3 |
| Weight (with cables) | kg | 0.15 |
| VPE 1 | 1 | |
| EAN 1 | 4021121518171 | |
| VPE 2 | 10 | |
| EAN 2 | 4021121518188 | |
| Customs tariff number | 85291095 |
